OAT PG HEAT
TRANSFER FLUID
SOLUTHERM™ OAT PG is a ready-to-use, propylene glycol-based thermal management fluid designed for the unique needs of Direct Liquid Cooling (DLC) in data centres, supercomputers, and adjacent end uses.
- For direct liquid cooling computer applications.
- Protects copper, stainless steel, aluminum, brass, and cast iron against corrosion.
- Formulated without 2-EHA, molybdate, and BNAS (borate, nitrite, amine, silicate).
Product Overview
SOLUTHERM™ OAT PG is a robust propylene glycol formulation for direct-to-chip cooling systems. PG 25 fluids have been shown to improve facility Power Usage Effectiveness (PUE), increase computing density and decrease data centre footprint when compared with air-cooled systems.
SOLUTHERM™ OAT PG leverages a proprietary Organic Acid Technology inhibitor system that offers long-life corrosion protection for copper, brass, steel, cast iron, and aluminum alloys.
OAT PG offers great performance evident by modified industry standard ASTM D8040 test designed by Open Compute Project (OCP) for corrosion protection.
Performance Features & Benefits
- For direct liquid cooling computer applications.
- Protects copper, stainless steel, aluminum, brass, and cast iron against corrosion.
- Formulated without 2-EHA, molybdate and BNAS (borate, nitrite, amine, silicate).
-
Product can be maintained with easy, periodic health monitoring and treatment as needed.
- Product offers high temperature corrosion protection for aluminum and is compatible with all aluminum heat exchangers.
- Product is designed to be more environmentally friendly through advanced formulation reducing the toxicity of the fluid compared to similar products.
Our versatile solutions are specifically formulated for the following applications:
Product Offering
| TYPICAL PROPERTIES | SOLUTHERM™ OAT PG 25 | SOLUTHERM™ OAT PG Concentrate | SOLUTHERM™ OAT PG Booster Pack |
|---|---|---|---|
| Propylene glycol % weight | 25% | 86% | Can be customized to prolong the life of fluid in existing systems. |
| Corrosion inhibitors and water % weight | 75% | 14% | |
| Colour | Fluorescent green | Fluorescent green | |
| ASTM Corrosion specification | D8039† | D8039 | |
| pH of solution | 8.3 | Depending on dilution | |
| Pounds per gallon 68°F (20°C) | 8.57 | 8.84 | |
| Boiling point** | 214°F (101°C) | Depending on dilution | |
| Freezing point | 15°F (-9°C) | Depending on dilution |
SOLUTHERM™ OAT PG 25
| Propylene glycol % weight | 25% |
| Corrosion Inhibitors and Water % Weight | 75% |
| Color | Fluorescent green |
| ASTM Corrosion specification | D8039† |
| pH of Solution | 8.3 |
| Pounds per gallon 68°F (20°C) | 8.57 |
| Boiling point** | 214°F (101°C) |
| Freezing Point | 15°F (-9°C) |
SOLUTHERM™ OAT PG Concentrate
| Propylene glycol % weight | 86% |
| Corrosion Inhibitors and Water % Weight | 14% |
| Color | Fluorescent green |
| ASTM Corrosion specification | D8039 |
| pH of Solution | Depending on dilution |
| Pounds per gallon 68°F (20°C) | 8.84 |
| Boiling point** | Depending on dilution |
| Freezing Point | Depending on dilution |
SOLUTHERM™ OAT PG Booster Pack
| Propylene glycol % weight | Can be customized to prolong the life of fluid in existing systems. |
| Corrosion Inhibitors and Water % Weight | |
| Color | |
| ASTM Corrosion specification | |
| pH of Solution | |
| Pounds per gallon 68°F (20°C) | |
| Boiling point** | |
| Freezing Point |
**Per ASTM D1120
