PG AL SAFE
HEAT TRANSFER FLUID
Aluminum Safe Heat Transfer Fluids are ready-to-use virgin propylene glycol-based heat transfer fluids containing a specially designed extended life inhibitor package that controls corrosion of metals, especially aluminum, copper and stainless steel.
- Specially formulated for aluminum and copper
- Operating temperature of -50°F to 250°F (-45.5°C to 121.1°C)
- Available in concentrate and dilutions of 30% to 70%
Product Overview
SOLUTHERM™ PG AL SAFE helps prevent scaling, and the fouling of heat transfer surfaces and maintains them in the optimum temperature operating range.
SOLUTHERM™ PG AL SAFE is specifically formulated to maintain the pH of the fluid within the Aluminum Safe Zone throughout the recommended operating temperature ranges from product freeze point up to 250°F (121.1°C), when mixed with appropriate water concentrations. It provides both freeze and burst protection for systems exposed to very low temperatures.
Performance Features & Benefits
- Fluid is dyed blue for leak detection purposes
- Specially formulated for aluminum and copper
- Extended life inhibitor package
- Inherently Biodegradable
- Meets the Heat Transfer Fluid ASTM D8039 and ASTM D3306* performance standards for multi-metal and Aluminum Heat rejection corrosion protection when a minimum of 30% is used
- Available in concentrate and dilutions of 30% to 70%
- Operating temperature of -50°F to 250°F (-45.5°C to 121.1°C)
*When used in accordance with ASTM D3306 recommended coolant concentration ranges
Our versatile solutions are specifically
formulated for the following applications:
Product Offering
| Typical Properties | SOLUTHERM™ PG AL SAFE | |||||
|---|---|---|---|---|---|---|
| Concentrate | 70 | 60 | 50 | 40 | 30 | |
| Propylene Glycol % Weight | 94% | 70% | 60% | 50% | 40% | 30% |
| Corrosion Inhibitors and Water % Weight | 6% | 30% | 40% | 50% | 60% | 70% |
| Color | Blue | |||||
| ASTM Specification | D8039, D3306* | |||||
| pH of Solution | Depending on Dilution | 7.8–8.8 | 7.8–8.8 | 7.8–8.8 | 7.8–8.8 | 7.8–8.8 |
| Pounds per Gallon (68°F) (20°C) | 8.73 | 8.76 | 8.74 | 8.71 | 8.65 | 8.58 |
| Boiling Point | Depending on Dilution | 230°F (110°C) | 225°F (107°C) | 222°F (106°C) | 219°F (104°C) | 216°F (102°C) |
| Freezing Point | Depending on Dilution | Below -60°F (-51.1°C) | <-60°F (-51.1°C) | -28°F (-33.6°C) | -7°F (-21.4°C) | 8°F (-13.0°C) |
SOLUTHERM ™ PG AL SAFE Concentrate
| Propylene Glycol % Weight | 94% |
| Corrosion Inhibitors and Water % Weight |
6% |
| Color |
Blue |
| ASTM Specification |
D8039, D3306* |
| pH of Solution | Depending on Dilution |
| Pounds per Gallon (20°C) | 8.73 |
| Boiling Point | Depending on Dilution |
| Freezing Point | Depending on Dilution |
SOLUTHERM ™ PG AL SAFE 70
| Propylene Glycol % Weight | 70% |
| Corrosion Inhibitors and Water % Weight |
30% |
| Color |
Blue |
| ASTM Specification |
D8039, D3306* |
| pH of Solution | 7.8-8.8 |
| Pounds per Gallon (20°C) | 8.76 |
| Boiling Point | 230°F (110°C) |
| Freezing Point | Below -60°F (-51.1°C) |
SOLUTHERM ™ PG AL SAFE 60
| Propylene Glycol % Weight | 60% |
| Corrosion Inhibitors and Water % Weight |
40% |
| Color |
Blue |
| ASTM Specification |
D8039, D3306* |
| pH of Solution | 7.8-8.8 |
| Pounds per Gallon (20°C) | 8.74 |
| Boiling Point | 225°F (107°C) |
| Freezing Point | <-60°F (<-51.1°C) |
SOLUTHERM ™ PG AL SAFE 50
| Propylene Glycol % Weight | 50% |
| Corrosion Inhibitors and Water % Weight |
50% |
| Color |
Blue |
| ASTM Specification |
D8039, D3306* |
| pH of Solution | 7.8-8.8 |
| Pounds per Gallon (20°C) | 8.71 |
| Boiling Point | 222°F (106°C) |
| Freezing Point | -28°F (-33.6°C) |
SOLUTHERM ™ PG AL SAFE 40
| Propylene Glycol % Weight | 40% |
| Corrosion Inhibitors and Water % Weight |
60% |
| Color |
Blue |
| ASTM Specification |
D8039, D3306* |
| pH of Solution | 7.8-8.8 |
| Pounds per Gallon (20°C) | 8.65 |
| Boiling Point | 219°F (104°C) |
| Freezing Point | -7°F (-21.4°C) |
SOLUTHERM ™ PG AL SAFE 30
| Propylene Glycol % Weight | 30% |
| Corrosion Inhibitors and Water % Weight |
70% |
| Color |
Blue |
| ASTM Specification |
D8039, D3306* |
| pH of Solution | 7.8-8.8 |
| Pounds per Gallon (20°C) | 8.58 |
| Boiling Point | 216°F (102°C) |
| Freezing Point | 8°F (-13.0°C) |
